Commercial Ceiling 400 L/day
DBA-GEC400LD
Maximum-capacity ceiling unit for demanding spaces
Industrial
About this unit
The GEC400LD handles up to 400L of moisture per day from a ceiling-mounted position. Designed for demanding industrial environments: warehouses, large commercial kitchens, sports facilities.
Highlights
- 400 L/day at 30°C 80%RH — 240 L/day at 26.7°C 60%RH
- 1270 × 1200 × 605 mm (W×D×H), 210 kg
- 65 dB(A) noise level, 3,250 CMH airflow
- 3,000–4,000 sq ft coverage
- RS485 Modbus standard; WiFi optional
- 3-phase 380V · 4,600W rated / 6,250W max
- R410A/1.9 kg × 2 refrigerant
Full specifications
| Model | DBA-GEC400LD |
|---|---|
| Dehumidifying Capacity(30℃ 80%RH) | 400L/Day |
| Dehumidifying Capacity(26.7℃ 60%RH) | 240L/Day |
| Cover Area | 3000-4000sqft |
| Air Flow | 3250m³/hr |
| Noise Level | 65dB |
| Voltage | 380V 3N / 50Hz |
| Rated Power | 4600W |
| Max. Power | 6250W |
| Rated Current | 10.2A |
| Max. Current | 12.5A |
| Refrigerant | R410A/1.9kg x 2 |
| Operational Temperature | 5-40℃ |
| Air Outlet Size | 985x228mm |
| Air Inlet Size | 965x430mm |
| Weight | 210kg |
| Dimension | L1270 × W1200 × H605mm |
Interested in the DBA-GEC400LD?
Get a no-obligation quote. We'll confirm sizing, ducting options and pricing for your space.
Enquire on WhatsApp Call +65 6772 9962 info@drytech.sg
Free download
Commercial Ceiling Series Catalog
Full specifications, dimensions, installation drawings and performance data for the complete Commercial Ceiling range — including the DBA-GEC400LD.
